Technical Data
Voltage: AC110/220v; 50HZ/60HZ
RF frequency: 2Mhz-4MHZ
RF Power: 10-200w
Needle cartridges: 10pin, 25pin, 64pin and Nano needle
Needle Thickness: 0.3mm
Needle Depth: 0.2-3.5mm (0.1step)
Intensity: 0 ~ 100 Level (10 Step)
Repetition: 0.2 / 0.5 / 1 / 2sec / Single
Treatment Duration: 0.1-0.6s
Suction level: 2 level
Control Display: 7inch color touch screen
Face Treatment
1. Non-surgical Face Lifting
2. Wrinkle Reduction
3. Skin Tightening
4. Skin Rejuvenation (Whitening)
5. Pore Reduction
6. Acne Scars
7. Scars
Body Treatment
1. Scars
2. Hyperhidrosis
3. Stretch Marks
4. Spider Veins (Veincure Option)
Cold Hammer: Help cool down, which is more conducive to skin recovery.
Function
Face Lift
Anti acne
Anti Wrinkle
Wrinkle Removal
Skin Rejuve
How it is works?
Fractional
RF Needle System through the special design of many fractional needles
point array, the high speed digital motor controls order through the
epidermis and the dermis accurate to control the depth of 0.25-3mm,
again by the end of the lattice needle release RF, stimulate collagen
and elastic tissue, and is the epidermal layer is safe, RF energy can
well to penetrate to the dermis, stimulate collagen protein hyperplasia,
not only is the best way to improve the scars, but also long-term
tightening skin wrinkles induced the good method.
Advantage
1. Treatment with vacuum, more comfortable.
2.Non Insulated Needles: It is possible to operate equal therapy to
Epidermis Layer and Dermis Layer as the needle do not have Insulation
Plating.
3.Stepping Motor Type: Different to existing Solenoid Type, the needle
inserts to the skin smoothly with no shock, and causes no bleeding and
no pain after the procedure.
4.Gold Plated Needles: Needle is durable and also has high
Biocompatibility by applying Gold Plating. Patient with metal allergy
could also use it with not concerning Contact Dermatitis.
5.Precise Depth Control. 0.5~5.0mm [0.1mm Step]; Operates epidermis layer
and dermis layer by Controlling the needle depth in unit of 0.1mm.
6. Safety Needle System:
-Sterilized disposable needle tip;
-Operator can easily notice the applying RF energy from a red light.
7.Elaborate Needle Thickness. Min: 0mm<Max: 0.3mm; The needle
structure is easy to penetrate the skin with minimum resistance.
